Mô tả sản phẩm:
| Performance | |
| Buffer Size (Mbit) | 4.2 |
| Switching Capacity (Gbps) | 56 |
| Forwarding Rate (64 bytes)(Mpps) | 41.7 |
| MAC Address Table | 8K |
| Max. Jumbo Frame (KB) | 9 |
| Ports | |
| 1 GbE | 24 |
| GbE/SFP Combo | 4 |
| PoE | |
| PoE+(802.3af/at) Ports | 24 |
| PoE Power Budget (watts) | 400 |
| Scheduled On/Off | o |
| Standard Compliance | |
| Ethernet Standards |
802.3af PoE
802.3at PoE+
802.3 10Base-T
802.3u 100Base-T
802.3ab 1000Base-T
802.1q Tag-based VLAN
802.3x Flow Control
802.3 Auto-Negotiation
802.1p Class of Service
802.1d STP
802.1w RSTP
802.3ad LACP
802.1AB LLDP
802.3az EEE
|
| Spanning Tree | |
| STP | o |
| RSTP | o |
| Link Aggregation | |
| Max. Number of Group | 8 |
| Max. Number of Member in Each Group | 8 |
| Type | LACP, Static |
| Traffic Load Balancing | o |
| VLAN | |
| Max. Number of VLAN | 255 |
| VLAN Type |
802.1q Tag-based VLAN
MAC-based VLAN
Protocol-based VLAN
Management VLAN
Voice VLAN
Surveillance VLAN
|
| Multicast | |
| IGMP Snooping | v2, v3(BISS) |
| IGMP Querier | o |
| ONVIF Surveillance | |
| Discovery | o |
| Surveillance Topology | o |
| Real-Time Video Streaming | o |
| ONVIF Device Maintenance |
Device Info
Network Settings
Time Settings
Reboot
Reset to Factory Default
|
| QoS | |
| Number of QoS Queues | 8 |
| Queue Schedule | SPQ, WRR |
| CoS (Class of Service) |
CoS
DSCP
CoS-DSCP
IP Precedence
|
| Rate Limiting | o |
| Security | |
| IP Source Guard | o |
| Traffic Control | DoS Defense, Storm Control |
| IP Conflict Prevention | o |
| Loop Protection | o |
| Management | |
| Local Service |
HTTP
HTTPS
Telnet
SSH v2
|
| Config Backup/Restore | o |
| 2-Level Administration Privilege | o |
| Access Control | Access List |
| OpenVPN Client | o |
| SNMP | v1, v2c, v3 |
| SNTP (Simple Network Time Protocol) | o |
| LLDP | o |
| Mail Alert |
Port Status
Port Speed
System Restart
IP Conflict
Hardware Monitor
Device Check
ONVIF IP Cam Snapshot
|
| VigorRouter Management (SWM) | o |
| VigorConnect Management (Since f/w) | V2.7.0 |
| VigorACS Management (Since f/w) | V2.7.0 |
| Physical | |
| Rack Mountable | 1U |
| Power Input | AC 100-240V @ 6.5A |
| Max. Power Consumption (watts) | 460.3 |
| Dimension (mm) | 440 x 281.3 x 44 |
