Mô tả sản phẩm:
| Interface | LAN Port: 8 x 10/100/1000/2500Mbps Ethernet, RJ-45 4x 1000Mbps/10Gbps SFP+ slot Console Port: 1x RJ-45 Button: 1x Factory Reset |
| Capacity | Buffer Size: 12Mbit Switching Capacity: 120 Gbps Forwarding Rate: 89.28 Mpps (64 bytes) MAC Address Table: 16k Jumbo Frame: Up to 10 KB L3 Routing Table: 6k static route + 512 prefix route |
| PoE | PoE Capable Ports: 8x PoE/PoE+ (802.3af/at), up to 30W per port, Type mode A PoE Power Budget: 140 watts Power Limit: Yes Scheduled On/Off: Yes Power Cycle on Port: Manual, Auto by Ping check timeout |
| Layer 3 Features | Static Route VLAN Route DHCP Server |
| Networking Standards | IP Version: IPv4, IPv6 Ethernet Standards: 802.3af PoE 802.3at PoE+ 802.3 10Base-T 802.3u 100Base-T 802.3ab 1000Base-T 802.3bz 2.5GBase-T 802.3ae 10GBase-X 802.3x Flow Control 802.3 Auto-Negotiation 802.1q Tag-based VLAN 802.1p Class of Service 802.1d STP 802.1w RSTP 802.1s MSTP 802.3ad LACP 802.1ad QinQ 802.1x Port Access Control 802.1AB LLDP 802.3az EEE |
| ONVIF Surveillance | Discovery Surveillance Topology Real-Time Video Streaming ONVIF Device Maintenance: Device Info, Reset Factory Default,Time Settings, Reboot |
| QoS | Number of QoS Queues: 8 Queue Scheduling: SPQ, WRR CoS (Class of Service): 802.1p CoS, DSCP, CoS-DSCP, IP Precedence Rate Limit & Shaping |
| Multicast | IGMP Snooping: v2, v3 (BISS) IGMP Querier MLD Snooping: v1, v2 (Basic) Max. Number of Multicast Group: 256 Group Throttling Group Filtering MVR (Multicast VLAN Registration) |
| Security | Access Control List: MAC, IPv4, IPv6 Storm Control: Broadcast, Unknown Multicast, Unknown Unicast DoS Defense 802.1x Port Access Control IP Source Guard IP Conflict Detection IP Conflict Prevention Loop Protection Dynamic ARP Inspection DHCP Snooping with Option 82 |
| VLAN | Max.Number of VLAN: 256 VLAN Type: 802.1q Tag-based, MAC-based, Protocol-Based, Management VLAN, Voice VLAN, Surveillance VLAN 802.1x Guest VLAN Port Isolation GVRP Q-in-Q: Basic |
| Link Aggregation | Max. Number of Group: 8 Max. Number of Member in: 8 Each Group Type: Static, LACP Traffic Load Balancing: MAC Address, IP/MAC Address |
| AAA | Authentication Server: RADIUS, TACACS+ Port Authorization: Management Account RADIUS Attribute Assignment: User Privilege, VLAN Accounting Multiple Server |
| Management | Web Interface: HTTP, HTTPS Command Line Interface: Telnet, SSH v2 OpenVPN Client: Certificate-based authentication User Authentication: Local Database, RADIUS, TACACS+ sFlow SNMP: v1, v2c, v3 Private MIB RMON Group: 1, 2, 3, 9 LLDP: LLDP-MED, Media Endpoint Discovery Extension Mail Alert: Port Status, Port Speed, System Restart, IP Conflict Syslog 2-Level Admin Privilege Multiple Admin Accounts Managed by VigorRouter SWM (since VigorConnect V1.8.0) Managed by VigorConnect Managed by VigorACS 3 (since ACS 3 V3.4.0) Config File Export/Import Dual Image SNTP Diagnostics Tools: Port Mirroring, Ping, Cable Test |
