Performance

NAT Session

60K

Max. NAT (Mbps)

700

Max. NAT with Hardware Acceleration : Single WAN (Mbps)

940

Max. NAT with Hardware Acceleration : Dual WAN (Mbps)

1800

WAN

SFP

1

Switchable WAN/LAN (GbE)

1

Cellular (via USB)

2

Wireless WAN (2.4GHz + 5GHz)

Yes

Internet Connection

IPv4

PPPoE

DHCP

Static IP

PPTP/L2TP

IPv6

PPP

DHCPv6

Static IPv6

TSPC

AICCU

6rd

6in4 Static Tunnel

802.1p/q Multi-VLAN Tagging

Yes

Multi-VLAN/PVC

Yes

Failover

Yes

Load Balancing

IP-based, Session-based

WAN Active on Demand

Link Failure, Traffic Threshold

Connection Detection

ARP, Ping, Strict ARP

WAN Data Budget

Yes

Dynamic DNS

Yes

DrayDDNS

Yes

LAN

Fixed LAN (RJ-45, GbE)

5

LAN Subnet

8

DMZ Port

1

VLAN

802.1q Tag-based VLAN

Port-based VLAN

Max. Number of VLAN

16

DHCP Server

Multiple IP Subnet

Custom DHCP Options

Bind-IP-to-MAC

LAN IP Alias

Yes

Wired 802.1x Authentication

Yes

Port Mirroring

Yes

Local DNS Server

Yes

Conditional DNS Forwarding

Yes

Hotspot Web Portal (Profile No.)

4

Hotspot Authentication

Click-Through

Social Login

SMS PIN

Voucher PIN

RADIUS

External Portal Server

Other Ports

USB

2

USB Type

2.0

Networking

Routing

IPv4 Static Route

IPv6 Static Route

Policy Route

Inter-VLAN Route

RIP v1/v2

BGP

Policy-based Routing

Protocol

IP Address

Port

Domain

Country

High Availability

Yes

DNS Security (DNSSEC)

Yes

IGMP

IGMP v2/v3

IGMP Proxy

IGMP Snooping & Fast Leave

Local RADIUS server

Yes

SMB File Sharing (Requires external storage)

Yes

VPN

LAN-to-LAN

Yes

Teleworker-to-LAN

Yes

Protocols

PPTP

L2TP

IPsec

L2TP over IPsec

SSL

GRE

IKEv2

IKEv2-EAP

IPsec-XAuth

OpenVPN

Wireguard

Max. VPN Tunnels

50

Max. OpenVPN + SSL VPN Tunnels

25

IPsec VPN Throughput (AES 256 bits) (single-directional) (Mbps)

250

SSL VPN Throughput (single-directional) (Mbps)

120

Wireguard VPN Throughput (single-directional) (Mbps)

80

User Authentication

Local

RADIUS

LDAP

TACACS+

mOTP

IKE Authentication

Pre-Shared Key, X.509

IPsec Authentication

SHA-1, SHA-256

Encryption

MPPE

DES

3DES

AES

VPN Trunk (Redundancy)

Failover, Load Balancing

Single-Armed VPN

Yes

NAT-Traversal (NAT-T)

Yes

VPN Matcher

Yes

Firewall & Content Filtering

NAT

Port Redirection

Open Ports

Port Triggering

DMZ Host

UPnP

ALG (Application Layer Gateway)

FTP, H.323, RTSP, SIP

VPN Pass-Through

IPsec, L2TP, PPTP

IP-based Firewall Policy

Yes

Content Filtering

APP

URL Keyword

DNS Keyword

Web Features

Web Category*(*subscription required)

DoS Attack Defense

Yes

Spoofing Defense

Yes

Bandwidth Management

IP-based Bandwidth Limit

Yes

IP-based Session Limit

Yes

QoS (Quality of Service)

TOS

DSCP

802.1p

IP Address

Port

Application

VoIP Prioritization

Yes

APP QoS

Yes

WLAN

2.4G WLAN

802.11n 2x2 MIMO

5G WLAN

802.11ac Wave 2 2x2 MU-MIMO

Antennas

2

Antenna Type

External Dipole

2.4G Gain (dBi)

2.5

5G Gain (dBi)

3

2.4G Max. Link Rate (Mbps)

400

5G Max. Link Rate (Mbps)

867

Max. Number of SSIDs per band

4

Security Mode

OWE

WEP

WPA

WPA2

Mixed(WPA+WPA2)

WPA3

Authentication

802.1X, Pre-Shared Key

WPS

PBC, PIN

WDS

Repeater (5GHz only)

Access Control

Access List

Client Isolation

Hide SSID

WLAN Scheduling

AirTime Fairness

Yes

Band Steering

Yes

WMM

Yes

Mesh (5G Only)

Root

Management

Local Service

HTTP

HTTPS

Telnet

SSH v2

FTP

TR-069

Config Backup/Restore

Yes

Config File Compatibility

Vigor2926

Firmware Upgrade

HTTP, TFTP, TR-069

2-Level Administration Privilege

Yes

Access Control

Access List, Brute Force Protection

Notification Alert

E-mail, SMS

Netflow

IPFIX, v5, v9

SNMP

v1, v2c, v3

Syslog

Yes

VPN Management

8

AP Management (APM)

20

Mesh (Number of manageable APs)

7

Switch Management (SWM)

10

VigorACS Management (Since f/w)

V4.2.0.1

Physical

Power Input

DC 12V @ 2A

Max. Power Consumption (watts)

24

Dimension (mm)

241 x 165 x 44
