Mô tả sản phẩm:
|
Performance |
|
| NAT Session | 300K |
| Max. NAT with Software Acceleration (single-directional) (Mbps) | 2200 |
| WAN | |
| Switchable WAN/LAN (GbE) | 3 |
| SFP/Ethernet Combo (WAN/LAN Switchable) | 1 |
| Internet Connection | |
| IPv4 |
PPPoE
DHCP
Static IP
|
| IPv6 |
PPP
DHCPv6
Static IPv6
TSPC
AICCU
6rd
6in4 Static Tunnel
|
| 802.1p/q Multi-VLAN Tagging | o |
| Multi-VLAN/PVC | o |
| Failover | o |
| Load Balancing | IP-based, Session-based |
| WAN Active on Demand | Link Failure, Traffic Threshold |
| Connection Detection | ARP, Ping, Strict ARP |
| WAN Data Budget | o |
| Dynamic DNS | o |
| DrayDDNS | o |
| LAN | |
| Fixed LAN (RJ-45, GbE) | 2 |
| LAN Subnet | 20 |
| VLAN |
802.1q Tag-based VLAN
Port-based VLAN
|
| Max. Number of VLAN | 20 |
| DHCP Server |
Multiple IP Subnet
Custom DHCP Options
Bind-IP-to-MAC
|
| LAN IP Alias | o |
| Wired 802.1x Authentication | o |
| Port Mirroring | o |
| Local DNS Server | o |
| Conditional DNS Forwarding | o |
| Hotspot Web Portal (Profile No.) | 4 |
| Hotspot Authentication |
Click-Through
Social Login
SMS PIN
RADIUS
External Portal Server
|
| Other Ports | |
| USB | 2 |
| USB Type | 2.0 + 3.0 |
| Networking | |
| Routing |
IPv4 Static Route
IPv6 Static Route
Policy Route
Inter-VLAN Route
RIP v1/v2
BGP
OSPF
|
| Policy-based Routing |
Protocol
IP Address
Port
Domain
Country
|
| Smart Action | o |
| High Availability | o |
| DNS Security (DNSSEC) | o |
| IGMP |
IGMP v2/v3
IGMP Proxy
IGMP Snooping & Fast Leave
|
| Local RADIUS server | |
| VPN | |
| LAN-to-LAN | o |
| Teleworker-to-LAN | o |
| Protocols |
PPTP
L2TP
IPsec
L2TP over IPsec
SSL
GRE
IKEv2
IKEv2-EAP
IPsec-XAuth
OpenVPN(Host to LAN)
Wireguard
|
| Max. VPN Tunnels | 200 |
| Max. OpenVPN + SSL VPN Tunnels | 50 |
| IPsec VPN Throughput (AES 256 bits) (single-directional) (Mbps) | 1000 |
| SSL VPN Throughput (single-directional) (Mbps) | 800 |
| User Authentication |
Local
RADIUS
LDAP
TACACS+
mOTP
TOTP
|
| IKE Authentication | Pre-Shared Key, X.509 |
| IPsec Authentication | MD5, SHA-1, SHA-256 |
| Encryption |
MPPE
DES
3DES
AES
|
| VPN Trunk (Redundancy) | Failover, Load Balancing |
| Single-Armed VPN | o |
| NAT-Traversal (NAT-T) | o |
| VPN Matcher | o |
| Firewall & Content Filtering | |
| NAT |
Port Redirection
Open Ports
Port Triggering
DMZ Host
UPnP
|
| ALG (Application Layer Gateway) | FTP, H.323, RTSP, SIP |
| VPN Pass-Through | L2TP, PPTP |
| IP-based Firewall Policy | |
| Content Filtering |
APP
URL Keyword
DNS Keyword
Web Features
Web Category*(*subscription required)
|
| DoS Attack Defense | o |
| Spoofing Defense | o |
| Bandwidth Management | |
| IP-based Bandwidth Limit | o |
| IP-based Session Limit | o |
| QoS (Quality of Service) |
TOS
DSCP
802.1p
IP Address
Service Type
|
| VoIP Prioritization | o |
| APP QoS | o |
| Management | |
| Local Service |
HTTP
HTTPS
Telnet
SSH v2
FTP
TR-069
|
| Config Backup/Restore | o |
| Firmware Upgrade | HTTP, TFTP, TR-069 |
| 2-Level Administration Privilege | o |
| Access Control | Access List, Brute Force Protection |
| Notification Alert | E-mail, SMS |
| SNMP | v1, v2c, v3 |
| Syslog | o |
| AP Managment (APM) | 50 |
| Switch Management (SWM) | 30 |
| VigorACS Management (Since f/w) | V3.9.3 |
| Physical | |
| Power Input | AC 110-220V @ 1A |
| Max. Power Consumption (watts) | 15 |
| Dimension (mm) | 273 x 171 x 45 |
