Mô tả sản phẩm:
|
Hardware Specifications |
|
|
Hardware Accelerated GE WAN Ports |
2 |
|
Hardware Accelerated GE RJ45 Ports |
6 |
|
Hardware Accelerated GE RJ45 FortiLink Ports |
2 |
|
USB Port |
1 |
|
Console Port (RJ45) |
1 |
|
Internal Storage |
64GB SSD |
|
Trusted Platform Module (TPM) |
Yes |
|
Bluetooth Low Energy (BLE) |
Yes |
|
Signed Firmware Hardware Switch |
Yes |
|
Antenna Ports (SMA) |
3 |
|
Wireless Interface |
Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax |
|
System Performance — Enterprise Traffic Mix |
|
|
IPS Throughput |
2.5 Gbps |
|
NGFW Throughput |
1.5 Gbps |
|
Threat Protection Throughput |
1.3 Gbps |
|
System Performance and Capacity |
|
|
Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
10 / 10 / 10 Gbps |
|
Firewall Latency (64 byte UDP packets) |
2.46 μs |
|
Firewall Throughput (Packets Per Second) |
15 Mpps |
|
Concurrent Sessions (TCP) |
1.4 M |
|
New Sessions/Second (TCP) |
100,000 |
|
Firewall Policies |
5000 |
|
IPsec VPN Throughput (512 byte) |
7.1 Gbps |
|
Gateway-to-Gateway IPsec VPN Tunnels |
200 |
|
Client-to-Gateway IPsec VPN Tunnels |
500 |
|
SSL-VPN Throughput |
N/A |
|
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
N/A |
|
SSL Inspection Throughput (IPS, avg. HTTPS) |
1.4 Gbps |
|
SSL Inspection CPS (IPS, avg. HTTPS) |
715 |
|
SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
140,000 |
|
Application Control Throughput (HTTP 64K) |
3.6 Gbps |
|
CAPWAP Throughput (HTTP 64K) |
6.8 Gbps |
|
Virtual Domains (Default / Maximum) |
10 / 10 |
|
Maximum Number of FortiSwitches Supported |
24 |
|
Maximum Number of FortiAPs (Total / Tunnel Mode) |
96 / 48 |
|
Maximum Number of FortiTokens |
500 |
|
High Availability Configurations |
Active-Active, Active-Passive, Clustering |
|
Dimensions |
|
|
Height x Width x Length (inches) |
1.6 x 8.5 x 6.3 |
|
Height x Width x Length (mm) |
40.5 x 216 x 160 |
|
Weight |
2.01 lbs / 1.03 kg |
|
Form Factor |
Desktop |
|
Operating Environment and Certifications |
|
|
Input Rating |
12V DC, 3A |
|
Power Supply Efficiency Rating |
80Plus Compliant |
|
Maximum Current |
100V/0.4A ,240V/0.2A |
|
Power Required |
Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
|
Power Consumption (Average / Maximum) |
16.9 W / 17.6 W |
|
Heat Dissipation |
60.02 BTU/hr |
|
Operating Temperature |
32°F to 104°F (0°C to 40°C) |
|
Storage Temperature |
31°F to 158°F (35°C to 70°C) |
|
Humidity |
10% to 90% non-condensing |
|
Noise Level |
Fanless |
|
Operating Altitude |
Up to 10,000 ft (3048 m) |
|
Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
|
Certifications |
USGv6/IPv6 |
