GE RJ45 WAN Interfaces

2

GE RJ45 Management/HA Ports

2

GE RJ45 Ports

14

GE SFP Slots

4

USB port

1

Console (RJ45)

1

Local Storage

1x 480GB SSD

Included Transceivers

0

System Performance — Enterprise Traffic Mix

IPS Throughput

2.2 Gbps

NGFW Throughput

1.8 Gbps

Threat Protection Throughput

1.2 Gbps

System Performance

Firewall Throughput (1518 / 512 / 64 byte UDP packets)

20 / 20 / 9 Gbps

Firewall Latency (64 byte UDP packets)

3 μs

Firewall Throughput (Packets Per Second)

13.5 Mpps

Concurrent Sessions (TCP)

2 Million

New Sessions/Second (TCP)

135,000

Firewall Policies

10,000

IPsec VPN Throughput (512 byte)

7.2 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

2,000

Client-to-Gateway IPsec VPN Tunnels

10,000

SSL-VPN Throughput

900 Mbps

Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)

500

SSL Inspection Throughput (IPS, avg. HTTPS)

820 Mbps

SSL Inspection CPS (IPS, avg. HTTPS)

1,000

SSL Inspection Concurrent Session (IPS, avg. HTTPS)

240,000

Application Control Throughput (HTTP 64K)

3.5 Gbps

CAPWAP Throughput (1444 byte, UDP)

1.5 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of FortiSwitches Supported

24

Maximum Number of FortiAPs (Total / Tunnel Mode)

128 / 64

Maximum Number of FortiTokens

5,000

Maximum Number of Registered FortiClients

600

High Availability Configurations

Active / Active, Active / Passive, Clustering

Dimensions

Height x Width x Length (inches)

1.75 x 17.0 x 11.9

Height x Width x Length (mm)

44.45 x 432 x 301

Weight

11.9 lbs (5.4 kg) / 12.12 lbs (5.5 kg)

Form Factor

Rack Mount, 1RU

Environment

Power

100–240V AC, 50–60 Hz

Maximum Current

110 V / 3 A, 220 V / 0.42 A

Power Consumption (Average / Maximum)

70.98 / 109.9 W

Heat Dissipation

374.9 BTU/h

Operating Temperature

32–104°F (0–40°C)

Storage Temperature

-31–158°F (-35–70°C)

Humidity

10–90% non-condensing

Noise Level

31.1 dBA

Operating Altitude

Up to 7,400 ft (2,250 m)

Compliance

FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI

Certifications

ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6
